60CBM concrete batch plant
Name: 60cbm Concrete Batching Plant
Category: Stationary concrete batching plant
Features:
1*40’HQ+1*20GP can load one complete set including all parts.
Various top quality make concrete mixer, famous control system,compact design.
Specification(form):
CBP60 concrete mixing plant is one of the middle size stationary mixing plants . Which consists of mixer, batch machine, scaling system and controlling system. We have been exporting to ASIA, AFRICA for more than 20years.
| CBP60(HZS60) | Unit | Parameter |
| Max Productivity | m3/h | 60 |
| Mixer Model | JS1000 | |
| Volume of Mixer | m3 | 1 |
| Batching Machine-Material Storage Bins | 3pcs *4m³ | |
| Batching Machine-Weighing Bins | liter | 1600-3/4 |
| Capacity Aggregate Scale | kg | 0-4000(±2%) |
| Max. Aggregate Size | mm | ≤60 |
| Capacity of Cement Scale | kg | 0-500(±2%) |
| Capacity of Water Scale | kg | 0-300(±2%) |
| Capacity of Addictive Scale | Kg | 0-40(±2%) |
| Volume of Manual Cement Loading Hopper | cbm/ton | 2.5/5 |
| Total Power | kW | 85 |
| Total Weight | t | 25 |
| Area for installation | ㎡ | 18*15 |
| Discharging height | m | 3.8 |
| Container numbers for shipment | NOS | 1*40’HQ+1*20GP |
